What are Hololight Space Network Requirements?

Port Requirements, TCP UDP, Spectator Ports & Multiuser Ports

Hololight Space uses a number of network ports to communicate data between the server and client. If these ports are closed, the features dependent on them won’t work. Below are the network ports that you need to open to fully use Hololight Space.

The table lists the default ports Hololight Space uses,but yYou can also define many of the ports these protocols use yourself. To do this, connect to Hololight Space with a client device, use the Quick hand menu, and go to Options > Meeting settings to change which ports Hololight Space uses.

Bandwidth Requirements

In Hololight Space, bandwidth consumption is primarily influenced by the resolution and frame rate of the streamed content. The current maximum bandwidth is set to 12 Mbit, which aligns with typical requirements for real-time rendering scenarios using Unity3D at high frame rates and resolutions.

Of course, in addition to bandwidth, maintaining low network latency is essential to ensure a smooth and responsive XR experience.

Protocols and Ports

If the network in which you are using Hololight Space doesn’t require use of Windows Defender Firewall, you can disable the firewall and use Hololight Space without opening specific ports. See Turn Microsoft Defender Firewall on or off for more information on how to enable and disable Microsoft Defender Firewall.

Hololight Space server and client connection
Protocol Local Port Remote Port
TCP 9999 -
TCP 50100 50100 - 50110
UDP 50100 50100 - 50110
UDP 50100 19302



Each new instance of Hololight Space you run on the server machine requires its own local port for Hololight Stream signaling. The first one is by default “9999”. Each additional instance of Hololight Space will then use the next port. For example, the second instance of Hololight Space will use port “10000”. The third will use port “10001”.

Hololight Space Standalone Runtime Broker
Application Protocol Protocol Local Port Remote Port
Desktop file loading TCP 17321 -
Hololight Space Meetings
Application Protocol Protocol Local Port Remote Port
Meeting connection and broadcasting TCP 5055 -
Meeting connection and broadcasting TCP 5056 -
Meeting connection and broadcasting TCP 5058 -
Meeting connection and broadcasting TCP 18200 - 18300[1] -
Additional meeting features TCP 20000 - 20100[1] -
Meeting connection and broadcasting UDP 5055 -
Meeting connection and broadcasting UDP 5056 -
Meeting connection and broadcasting UDP 5058 -
Meeting connection and broadcasting UDP 18200 - 18300[1] -
Additional meeting features UDP 20000 - 20100[1] -
Additional Features
Application Protocol Protocol Local Port Remote Port
Hololight Spectator connection TCP 10090[1] -
Hololight Spectator connection UDP 10090[1] -



[1] You can change this value in Hololight Space. Using the Quick hand menu, go to Options > Meeting settings to change which ports Hololight Space uses.
